Zones Amplifier
Suitable for small and medium-sized indoor venues such as small and medium supermarkets, shopping malls, casual cafes and other small and medium-sized indoor venues for background music playback and small and medium-sized background music playback.
Class-D amplifier circuitry.
BASS and TREBLE tone controllers.
Powersupply AC100-240V and DC24V.
EMCinput has priority over the other inputs.
70/100-volt and 4~16 ohms(Ω) output loads.
SMT circuit boards with highly stable performance.
Built-in USB player,FM tuner and Bluetooth receiver.
High-definition display for the working status of playing programme.
Individual volume controller for inputs,and master volume controller for all.
Two microphone (MlC1& MIC2) jacks,MlC2 supports 48V Phantom Power with switch ON/OFF.
Protection provided for output short circuit,overload,high temperature,peakcurrent limiters
Product Model | MA-60 | MA-120 |
Rated Power | 60W | 120W |
Output Mode | Lowimpedance:4/8 ohms(0),Woltage line:70V& 100V | |
Compatible Media | UsB,SD,Bluetooth,FM,Aux In | |
Playable Formats | MP3.WMA,WAVFLAC.APE | |
Bluetooth Name | BGM SYSTEM | |
Bluetooth Frequency | 2402-2480 MHz | |
Bluetooth E.1.R.P | 2 dBm | |
FM Tuner Frequency | 87.50~107.50 MHZ | |
Frequency Response | 60 Hz~15k Hz (± 3 dB) | |
THD | <1% at 1kHz,1/3 rated power | |
S/N | ≥75dB | |
Tone Control | BASS:100 Hz(+ 10 dB),TREBLE:10k Hz (± 10 dB) | |
Protection | Short circuit,overload,high temperature | |
AC Power Supply | AC230V/50Hz.0.33A | |
AC Fuse | T3.15A | T3.15A |
DC Power Supply | DC24V,3.13A | |
Power Cord | (3×0.75mm2)×1.5M | |
Power Consumption | 84W | 168W |
Dimensions | 71(H)×300(W)×191(D) mm | |
Packing Size | 120(H)×350(W)×255(D)mm | |
N.W | 4.8kg | 5.2kg |
G.W | 5.5kg | 5.9kg |
