Wireless Conference
Apply to the venues of all sizes where voice evacuation is needed: shopping malls, plazas, hospitals, exhibition & convention centers, star hotels, schools, etc.
Supports Mode: Limit (1/2/3/4),FIF0(1/2/3/4), Chairman Only.
Supports discuss and video tracking.
2.4inch LCD display system information.
Multiple sets of equipment can be used simultaneously indifferent rooms in the same place.
Audio Part：
Technical Parameter | |
Transmission Method | Wireless infrared |
Audio Channel | 5 |
Carrier Frequency band | 2MHz-3MHz |
Modulation Method | FM/FSK |
Receiving Sensitivity | -100dBM |
Output Level | 0dB/+6dBV |
Infrared Operating Distance | >15M |
Frequency Response | 80Hz-10kHz |
S/N Ratio | >82dB |
T.H.D. | <0.5% |
Data Part：
Technical Parameter | |
Transmission Method | Wireless |
Data Channel | 100 |
Frequency Range | 422.4MHz-471.9MHz |
Modulation Method | FSK |
Receiving Sensitivity | -80dBM |
Transmission Consumption | 10dBM |
Communication Rate | 100KBPS |
Signal Covering Range | Radius 100M |
System Power Supply | AC110V-240V150HZ~60HZ |
Consumption Rating | 10W |
Dimensions | 483x377x88mm,2 U rack 19" |
Operating Temperature Range | 0-40 degree |
N.W | 6.81kg |
