Wireless Conference
Apply to the venues of all sizes where voice evacuation is needed: shopping malls, plazas, hospitals, exhibition & convention centers, star hotels, schools, etc.
Directional Antenna Technology Index:
Directional Antenna | |
Antenna Type | Log Periodic Dipole Array（LPDA） Antenna |
The Working Frequency Band | 500MHz-1GHz |
Working Voltage | 8V DC |
Gain | 6dB Typical , Maxinum 10dB |
Impedence | 50Ω ,Typical |
VSWR | ≤1.7:1 |
Direction | Oval Typical |
Direction Polarity | Vertical |
Number of Segments for Wave Guides | 11segments |
Connecting Terminal | Fixed Right-angel BNC Pcb Jack |
Weight | 310gram |
Dimension | 348mm×325mm×25mm |
Structure | Glass Copper and Copper Film Coating |
Coating | Dusky Black |
