Power Amplifier
Suitable for villas, fitness studios, dance studios, public or private gardens, small and medium-sized supermarkets, shops, markets, stations
5 LED indicators for status display
Output mode：4-16ohm,70V/100V
Rated power：360W/460W/660W
RCA&XLR input socket for convenient link
220-240V AC Power and 24V DC power working voltage
Product Model | PA-360 | PA-460 | PA-660 |
Rated Power | 360W | 460W | 660W |
Output Mode | 4-16 ohms and 70V/100V | ||
LINE Input | 10k ohms 1V (0 dB) , Unbalanced | ||
LINE Output | 10k ohms 0.775V (0 dB) , Unbalanced | ||
Frequency Response | 60Hz-15kHz(+3dB) | ||
THD | 0.5% at 1kHz,1/3 rated power | ||
S/N | >70 dB | ||
Cooling Fan | DC 12V FAN | ||
LED Indicators | POWER,SIGNAL,CLIP,PROTECT | ||
Power Supply | AC120V 60Hz | ||
Power Consumption | 485W | 620W | 880W |
Dimensions | 89(H)x483(W)x366(D)mm | ||
Weight | 15.12kg N.W | 17.66kg N.W | 19.74kg N.W |
