Power Amplifier
Suitable for villas, fitness studios, dance studios, public or private gardens, small and medium-sized supermarkets, shops, markets, stations
Rated power：1000W/1500W/2000W
Output mode：4-16ohm,70V/100V
220-240V AC Power and 24V DC power working voltage
5 LED indicators for status display
RCA&XLR input socket for convenient link
Product Model | PA-1000 | PA-1500 | PA-2000 |
Rated Power | 1000W | 1500W | 2000W |
Output Mode | 4-16 ohms (Ω) fixed resistance output, 70V, 100V constant pressure output | ||
MIC Input | 10k ohms(Ω) 0.775V (0) | ||
LINE Output | 10k ohms(Ω) 0.775V (0) | ||
Frequency Response | 60Hz~15kHz(± 3dB) | ||
S/N | <0.5% at 1kHz,1/3 rated pow | ||
THD | >85 D | ||
Cooling Fan | DC 12V FA | ||
LED Indicator | POWER,SIGNAL, CLIP,PROTEC | ||
Power Supply | Optional | ||
Power Consumption | 1350W | 2000W | 3000W |
Dimensions (WxDxH) | 132(H)×486(W)×483(D)mm 3U | ||
Dmimensions | 225(H)×610(W)×585(D)mm | ||
Weight | 27.5kg N.W 31.5kg G.W | 34kg N.W 34kg G.W | 34.5kg N.W 38.5kg G.W |
